Airports lights system

Discover our awarded VISTA system, designed for non-instrument runways or non-precision approach runways.
Signalight airport lighting solutions provide our clients maximum safety. Our products are easy to install into any kind of infrastructure and we ensure you the technical support for the best usability.

Airports lights system comprises medium or low intensity and is intended for small and medium-size airports. The design of the runway lighting system is similar with the high intensity systems but the lamps have a lower brightness output, 10% or 30% of ICAO requirements for CAT Airports.

VISTA - Airports lights system +

We consider high-intensity systems lamps fully compliant with ICAO Isocandela diagrams. These values are achieved when the lamps are powered to 100% intensity on step 5 of the CCR. Our medium intensity lamps are similar to 30% of a high-intensity lamp or what you get from a high-intensity system on step 4. The low-intensity lamps are similar to 10% of a high-intensity lamp or what you get from a high-intensity system on step 3.

In a low or medium intensity lighting system we have the possibility of controlling the lighting on three levels: 10, 30 and 100%.
So, in a high intensity system we have all 5 levels of intensity. In a medium intensity system we will have levels 2, 3 and 4 and in a low-intensity system we have levels 1, 2 and 3.

The power supply system is a series, in constant current, similar to a classic CCR. The difference consists in the fact that if at a CCR there is an alternating current, of 6.6 A in 5 levels, in our system we have direct current of a maximum of 1.4 A in three levels. Our system does not need current transformers. The voltage level is much lower in our system, of a maximum of 350 V DC.

The controllers used can have a maximum of 8 circuits, each circuit of a maximum 500 W. A system with a maximum power of 4000 W can be obtained. A lamp in the system has an average of 10 W, so an average of 400 lamps can be powered. This number is generally more than enough for a runway light system for a small or medium airport.
We also offer lamps powered by 110 V AC or 230 VAC. They have no light intensity control and require a simple power supply panel.

The lamps are elevated mounted on the base plates, with frangible coupling or on shallow bases. Another mounting option is on fiberglass pyramids.

In a system we can have:

Lamps:

– runway edge
– approach
– threshold
– end
– combined threshold / end
– taxi lights

Guidance:

Guidance signs
Runway guard lights
Wind cone
APAPI or PAPI system
APRON floodlighting system

Control:
– Controller 1 to 8 independent ON / OFF circuits  + brightness
– optional:
– remote console
– PC console
– Air to ground radio control
– GSM modem

Download presentation of Airports lights system:

Airports lights system
